    Single Impeller Vertical Submersible Vortex Pump Electric Two Phase Fluid Pump

    Ask Lasest Price
    Brand Name : Chengdu Yongyi
    Model Number : XLY
    Price : USD500-5000/set
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
    Supply Ability : 300 sets per month
    Delivery Time : 25 working days after receiveing advance payment
    Certification : ISO9001
    • Product Details
    • Company Profile

    Single Impeller Vertical Submersible Vortex Pump Electric Two Phase Fluid Pump

    Single Impeller Vertical Submersible Vortex Pump Electric Two Phase Fluid Pump


    Brief Introduction

    XLY-series vertical vortex pumpsadoptvortex impeller. The impeller rotates in the pump body, and the inner pressure of the medium drives the medium in the pump body to rotate to form the eddy. The medium will be driven out from the pump outlet.Relative movement does not occur between the impeller and the impeller blade,, so that the service life of the impeller is greatly extended, and it’s three times as long as that of conventional centrifugal pump impeller.A gap (30-90mm) between pump body and the front cover can prevent impeller from being stuck because of solids and it can make flow passage components free from frequent scaling. In this way, the service life of the impeller is greatly extended and problems like short service life, frequent maintenance and high consumption are well solved.

    Application


    -- Corrosive liquid containing less than 45% solid particles (particle size is no more than 20mm)

    -- Chemical Industry

    -- Fertilizer Industry

    -- Petroleum Industry

    -- Paper Industry

    -- Metallurgy Industry

    -- Other Industries.


    Single Impeller Vertical Submersible Vortex Pump Electric Two Phase Fluid Pump


    Performance Data


    ModelXLY-series submerged vortex pump
    Discharge Size40mm-150mm
    Inlet Size65mm-200mm
    Capacity15~350m³/h
    Head18~60m
    Maximal Efficiency20%~51%
    NPSH1m~4m
    Allowable Max Motor Powerup to 110kw
    Allowed Max Particle Size20mm
    Pump Weighup to 1500kg
    RPM1450r/min
    Diameter180mm~400mm

    Technical Parameter


    Model

    Flow (m³/h)

    Head (m)

    Speed(r/min)

    Efficiency(%)

    40XLY-250

    15-30

    18-25

    1450

    20-25

    40XLY-315

    15-30

    25-40

    1450

    20-26

    50XLY-250

    30-50

    18-25

    1450

    20-28

    50XLY-315

    30-50

    25-40

    1450

    22-30

    50XLY-400

    30-50

    40-60

    1450

    26-33

    65XLY-250

    50-80

    18-25

    1450

    30-39

    65XLY-315

    50-80

    25-40

    1450

    34-43

    65XLY-400

    50-80

    40-60

    1450

    35-48

    80XLY-250

    80-120

    18-25

    1450

    35-44

    80XLY-315

    80-120

    25-40

    1450

    39-46

    80XLY-400

    80-120

    40-60

    1450

    39-47

    100XLY-315

    120-160

    20-40

    1450

    40-48

    100XLY-400

    120-160

    40-60

    1450

    41-50

    125XLY-315

    160-240

    20-40

    1450

    40-49

    125XLY-400

    160-240

    40-60

    1450

    42-50

    150XLY-315

    240-350

    20-40

    1450

    43-49

    150XLY-400

    240-350

    40-60

    1450

    43-51


    Advantages


    • high safety and reliability, strong versatility and wide application range
    • bracket support, front and rear door opening
    • safe and convenient to disassemble and maintain with lower cost
    • wide flow channel, makes the pump adaptable to working conditions

    Product Dispaly


    FAQ


    1. Q: Are you a manufacturer or trading company?
    A: We are a manufacturer established in 1995, professional manufacturer of chemical-process pump and energy-saving mixer with more than 20-year experience.
    2. Q: What's your delivery time?
    A: The batch order will be shipped within 40 working days after receiving deposit.
    3. Q: What's your warranty service policy?
    A: 12 Months for all products, and some products warranty is 24months.
    4. Q: What information I need to offer for quotation?
    A: Medium: ____________ PH: ________
    Specific Gravity: _______ Temperature: _________
    Capacity/Flow: ________m3/h Head: _________m
    Voltage: ____________V Frequency: _________Hz
    Power:_____________KW
    5. Q: What is your minimum quantity?
    A: One set is also welcomed to us.
